1:High temperature tolerance
2:High thermal conductivity
3:Excellent oxidating resistance.
4:Corrosion resistance
5.Long service life
Inquiry
|
Product Overview
3D Printed Reaction Bonded Silicon Carbide (RBSC / SiSiC) Components are advanced ceramic structural parts manufactured using additive manufacturing technology combined with reaction sintering processes. This innovative manufacturing method enables the production of complex geometries, lightweight structures, and large integrated components that are difficult or impossible to achieve through conventional forming methods.
Compared with traditional ceramic manufacturing technologies, 3D printing significantly improves design flexibility, reduces tooling costs, shortens development cycles, and allows customized production according to customer requirements.
RBSC/SiSiC materials provide outstanding mechanical strength, wear resistance, corrosion resistance, thermal conductivity, and dimensional stability, making them ideal for demanding applications in semiconductor, photovoltaic, mining, chemical processing, metallurgy, and energy industries.
Key Features
Complex Geometry Capability
3D printing enables the fabrication of intricate internal channels, lattice structures, lightweight designs, and integrated assemblies without traditional molds.
Large Integrated Components
Manufacture large-size monolithic structures with reduced assembly requirements and improved structural reliability.
High Mechanical Strength
Reaction bonded silicon carbide combines excellent rigidity and strength for demanding industrial environments.
Outstanding Wear Resistance
Exceptional hardness provides superior resistance to abrasion, erosion, and particle wear.
Excellent Corrosion Resistance
Highly resistant to acids, alkalis, salts, and aggressive chemical media.
High Temperature Stability
Maintains excellent performance under long-term high-temperature operating conditions.
High Thermal Conductivity
Facilitates efficient heat transfer and minimizes thermal gradients.
High Purity and Low Contamination
Suitable for semiconductor and photovoltaic manufacturing environments requiring ultra-clean process conditions.
Technical Properties
Property
Typical Value
Material
Reaction Bonded Silicon Carbide (RBSC / SiSiC)
Density
≥ 3.02 g/cm³
Open Porosity
< 1%
Hardness
Mohs 9.2–9.5
Flexural Strength
≥ 250 MPa
Elastic Modulus
≥ 330 GPa
Thermal Conductivity
≥ 45 W/m·K
Maximum Operating Temperature
1380–1450°C
Water Absorption
Nearly Zero
| Property | Typical Value |
|---|---|
| Material | Reaction Bonded Silicon Carbide (RBSC / SiSiC) |
| Density | ≥ 3.02 g/cm³ |
| Open Porosity | < 1% |
| Hardness | Mohs 9.2–9.5 |
| Flexural Strength | ≥ 250 MPa |
| Elastic Modulus | ≥ 330 GPa |
| Thermal Conductivity | ≥ 45 W/m·K |
| Maximum Operating Temperature | 1380–1450°C |
| Water Absorption | Nearly Zero |
Typical Products
Semiconductor & Photovoltaic Components
- SiC Boat Brackets
- SiC Boat Supports
- SiC Cantilevers
- SiC Paddles
- SiC Wafer Carriers
- SiC Furnace Fixtures
- LPCVD Furnace Components
- Diffusion Furnace Components
Wear-Resistant Industrial Components
- Silicon Carbide Volute Liners
- Silicon Carbide Throatbushes
- Silicon Carbide Impellers
- Silicon Carbide Pump Parts
- Hydrocyclone Liners
- Apex Nozzles
- Vortex Finders
- Desanding Nozzles
High Temperature Structural Components
- Kiln Furniture
- Support Beams
- Rollers
- Burner Nozzles
- Heat Treatment Fixtures
- Customized Structural Parts
Industries Served
Semiconductor Industry
High-purity SiC components for diffusion furnaces, LPCVD systems, oxidation furnaces, and semiconductor processing equipment.
Photovoltaic Industry
Advanced SiC structural components for TOPCon, HJT, and high-efficiency solar cell production lines.
Mining Industry
Wear-resistant SiC pump and hydrocyclone components for slurry handling and mineral processing.
Chemical Industry
Corrosion-resistant components for aggressive chemical processing environments.
Energy & Environmental Industry
FGD systems, waste treatment, high-temperature process equipment, and energy applications.
Manufacturing Advantages
✔ Advanced 3D Printing Technology
✔ Complex Shape Manufacturing
✔ Large Integrated Structures
✔ High Precision Machining
✔ Fast Prototype Development
✔ Reduced Tooling Cost
✔ Customized Design Support
✔ OEM & ODM Manufacturing
✔ Global Export Experience
Why Choose Our 3D Printed SiC Components
By combining additive manufacturing with reaction bonded silicon carbide technology, we deliver high-performance ceramic solutions that offer superior design freedom, enhanced durability, and reduced total ownership costs. From semiconductor furnace structures to mining wear components, our customized SiC products help customers improve equipment performance and operational efficiency.
